CIMC-D06-03C Rear Corner Post InnerEnhance container security with CIMC Equilink's robust Security Shipping Container Rear Corner Post Outer. Durable, reliable, and designed to safeguard your cargo. Explore our solutions today!
Product parameters
PART NO. Product Name Material Net Weight(KGS) Specification
CIMC-D06-01A Rear Corner Post Outer Corten 37.077 6.0X50X40X232X2400
CIMC-D06-01A-1 Rear Corner Post Outer Corten 37.386 6.0X50X40X232X2420
CIMC-D06-01A-2 Rear Corner Post Outer Corten 37.664 6.0X50X40X232X2438
CIMC-D06-01A-20 Rear Corner Post Outer Corten 27.565 4.5X30X230X40X50X2379
CIMC-D06-01A-21 Rear Corner Post Outer Corten 29.250 6.0X55X45X130X2700
CIMC-D06-01A-3 Rear Corner Post Outer Corten 36.753 6.0X50X40X232X2379
CIMC-D06-01A-Q Rear Corner Post Outer Corten 37.077 6.0X50X40X232X2400
CIMC-D06-01B Rear Corner Post Outer Corten 41.712 6.0X50X40X232X2700
CIMC-D06-01B-1 Rear Corner Post Outer Corten 42.021 6.0X50X40X232X2720
CIMC-D06-01B-2 Rear Corner Post Outer Corten 42.376 6.0X50X40X232X2743
CIMC-D06-01B-3 Rear Corner Post Outer Corten 42.098 6.0X50X40X232X2725
CIMC-D06-01B-4 Rear Corner Post Outer Corten 41.356 6.0X50X40X232X2677
CIMC-D06-01B-5 Rear Corner Post Outer Corten 39.919 6.0X50X30X230X2684
CIMC-D06-01B-6 Rear Corner Post Outer Left Corten 39.919 6.0X50X30X230X2684
CIMC-D06-01B-Q Rear Corner Post Outer Corten 41.712 6.0X50X40X232X2700
CIMC-D06-02A Rear Corner Post Outer Corten 38.999 6.0X70X39X230X2400
CIMC-D06-02A-1 Rear Corner Post Outer Corten 39.324 6.0X70X39X230X2420
CIMC-D06-02A-Q 0 Corten 38.999 6.0X70X39X230X2400
CIMC-D06-02B Rear Corner Post Outer Corten 43.874 6.0X70X39X230X2700
CIMC-D06-02B-1 Rear Corner Post Outer Corten 43.614 6.0X70X39X230X2684
CIMC-D06-02B-2 Rear Corner Post Outer Corten 44.280 6.0X70X39X230X2725
CIMC-D06-02B-3 Rear Corner Post Outer Corten 44.572 6.0X70X39X230X2743
CIMC-D06-02B-4 Rear Corner Post Outer Corten 45.499 6.0X70X39X230X2800
CIMC-D06-02B-Q 0 Corten 43.874 6.0X70X39X230X2700
CIMC-D06-02C Rear Corner Post Outer Corten 21.746 6.0X40X115X40X2700
CIMC-D06-02C-1 Rear Corner Post Outer Corten 19.491 6.0X40X115X40X2420
CIMC-D06-02D Rear Corner Post Outer Corten 25.494 4.5X50X40X232X2374
CIMC-D06-03A Rear Corner Post Inner Corten 29.184 10X113X40X2353
CIMC-D06-03B Rear Corner Post Inner Corten 34.130 12X113X40X2353
CIMC-D06-03B-1 Rear Corner Post Inner Corten 28.600 12X113X40X1938
CIMC-D06-03B-1-ZG 0 Corten 28.600 12X113X40X1938
CIMC-D06-03B-ZG 0 Corten 32.690 12X113X40X2353
CIMC-D06-03C Rear Corner Post Inner Corten 38.540 12X113X40X2657
CIMC-D06-03C-ZG 0 Corten 36.930 12X113X40X2657
CIMC-D06-04A Rear Corner Post With Inner Channel Corten 66.261 6.0X50X40X232X2400&10X113X40X2353
CIMC-D06-04B Rear Corner Post With Inner Channel Corten 69.796 6.0X50X40X232X2400&12X113X40X2353
CIMC-D06-04C Rear Corner Post With Inner Channel Corten 78.657 6.0X50X40X232X2700&12X113X40X2657
CIMC-D06-05A Rear Corner Post With Inner Channel Corten 71.717 6.0X70X39X230X2400&12X113X40X2353
CIMC-D06-05B Rear Corner Post With Inner Channel Corten 80.819 6.0X70X39X230X2700&12X113X40X2657
CIMC-D06-06 0 Corten 102.753
CIMC-D06-07A Rear Corner Post Outer Corten 27.874 6.0X30X175X45X43X2200
